STIC Incentive Funding Grant Awarded for Local Aid Software Training

Posted on August 20, 2020August 21, 2020

FHWA recently announced the award of a State Transportation Innovation Council (STIC) funding grant ($38,490) to support NJDOT’s Division of Local Aid and Economic Development in their efforts to deliver software training to NJDOT and local transportation agency staff to perform electronic plan reviews.

The STIC-funded training initiative will be provided in conjunction with NJDOT’s efforts to implement features of the Project Management and Reporting System (PMRS), initially launched in 2018, to establish electronic document management, electronic plan review, and other 21^st century project management innovations to help make project management more efficient. The PMRS is also being designed to integrate with tools, such as Bluebeam® Revu® and geographic information systems (GIS), to enable collaborative plan review and georeferencing project data.

NJDOT is continuing with its plan for an enterprise innovation shift to electronic project management. The NJDOT Division of Local Aid is about to implement Phase 2 of the PMRS. This implementation includes transitioning plan review from a paper-based process to an electronic process offering greater standardization and tracking capabilities. The Department’s shift is well-aligned with EDC-3’s e-Construction initiative and Local Aid’s objectives to improve program delivery through electronic review.

With this shift, Local Aid project managers will have easier access to project plans and documents from the District Offices in electronic formats from anywhere. The innovations embedded in the platform and supporting software will enable easy file sharing, efficient project transfers, tracking comments and their resolution, and the ability to track and review previous project phases more efficiently.

The STIC funding will support the NJDOT Division of Local Aid in the development of a software training program for municipal and county engineers and Local Aid staff. The training will be conducted over a two-month period with various morning and afternoon classes to offer flexibility in scheduling and attendance. The initial “live” training sessions are expected to be recorded for future online, “on-demand” use. The course development and training initiative will be carried out by a team that manages the Local Aid Resource Center in association with NJDOT Local Aid staff.

The training seeks to accomplish key goals aligned with the Department’s commitment to using technology to enable staff to be more efficient in accomplishing routine tasks and collaborative activities with external stakeholders. Ultimately, the transition to an online tool is expected to reduce paper consumption as well as centralize and standardize project management activities.

Click on NJ STIC Incentive Funding Grants to get more information on the purpose, eligibility and uses for which the NJ STIC has sought incentive funding in recent years.

Pavement Preservation Treatments at NJDOT

Posted on July 20, 2020August 18, 2020

NJDOT's Pavement and Drainage Management and Technology Unit is advancing the use of Pavement Preservation treatments on the state's roads to increase safety, enhance durability, improve customer experience and minimize costs. Pavement rehabilitation is needed for deficient roadways, but pavement preservation can extend pavement life for state highways in good and fair condition.

Watch this educational video to learn more about the Pavement Preservation program at NJDOT and the tools in the pavement preservation toolbox. The video explains the rationale for maintaining roads in a state of good repair and establishing a dedicated program for pavement preservation. The video highlights several pavement preservation treatments in the NJDOT toolbox and how, when and why the treatments are used.

Development of Real-Time Traffic Signal Performance Measurement System

Posted on June 12, 2020June 12, 2020

Adaptive Signal Control Technology (ASCT) is a smart traffic signal technology that adjusts timing of traffic signals to accommodate changing traffic patterns and reduce congestion. NJDOT recently deployed this technology in select corridors and required a set of metrics to gauge functionality and effectiveness in easing traffic congestion and reliability. However, the monitoring and assessment of the ASCT performance at arterial corridors has been a time-consuming process.

The Automated Traffic Signal Performance Measures system (ATSPMs) developed by Utah DOT is one of the widely-used platforms for traffic signal performance monitoring with a large suite of performance metrics. One limitation of the existing ATSPM platform is its dependency on high-resolution controllers and the need to set up hardware and software at each individual intersection. Upgrading the existing controllers and reconfiguring the hardware and software at each intersection requires significant investment of funding and labor hours.

Recently completed research funded by the New Jersey Department of Transportation’s Bureau of Research mobilized researchers from Rutgers University, The College of New Jersey (TCNJ), and Rowan University to assist in advancing the goal of establishing automated traffic signal performance measures. The goals of the needed research were to develop a prototype Automated Traffic Signal Performance Measures platform for ASCT systems. The main focus was how to take advantage of the centrally-stored signal event and detector data of ASCT systems to generate the ATSPM performance metrics without intersection-level hardware or software deployment.

The study’s primary objectives were to examine: 1) how to utilize existing field data and equipment to establish Signal Performance Measures (SPMs) for real-time monitoring; and 2) identify what additional data and equipment may be employed to generate additional SPMs while automating the real-time traffic signal monitoring process. This research is especially important for New Jersey (NJ) with the deployment of ATSPM and the establishment of NJDOT’s Arterial Management Center (AMC).

Background

At present, NJDOT maintains a traffic signal system comprised of many types of equipment that affect signal performance, including different signal configurations and vehicle detection devices. Older equipment and ineffective detection technologies make real-time traffic signal monitoring quite difficult to implement across the state. With the implementation of more centrally-controlled traffic signal systems and the Department’s Arterial Management Center (the central control for remotely monitoring these signals) coming online, NJDOT needed standards to assure that the signals would operate properly and ease traffic congestion, and that the signals could be monitored remotely in real-time effectively.

ATSPMs are promoted by FHWA (Federal Highway Administration) as an EDC-4 (Every Day Counts 4) initiative. The use of ATSPMs has important foreseeable benefits:

Increased Safety. A shift to proactive operations and maintenance practices can improve safety by reducing the traffic congestion that results from poor and outdated signal timing.
Targeted Maintenance. ATSPMs provide the actionable information needed to deliver high-quality service to customers, with significant cost savings to agencies.
Improved Operations. Active monitoring of signalized intersection performance lets agencies address problems before they become complaints.
Improved Traffic Signal Timing and Optimization Policies. Agencies are able to adjust traffic signal timing parameters based on quantitative data without requiring a robust data collection and modeling process.

Research Approach

The research team recognized that the deployment of various adaptive traffic control systems such as InSync and SCATS systems on major NJ corridors and networks improved the capability for building real-time performance measures. The study included: a review of the literature and best practices; several stakeholder meetings; and recommendations and development of performance metrics, system architectures, data management, and strategies for deploying ATSPM systems using existing and planned NJDOT arterial infrastructure and technologies.

Figure 1. An Example real-time performance monitoring on County Road 541 and Irwick Road, Burlington County, NJ

The researchers first conducted a literature review to identify examples of existing Signal Performance Measurement (SPM) systems to help inform the development of ATSPMs. The researchers described several exemplary initiatives, including the following:

In 2013, the Utah Department of Transportation’s (UDOT) SPM Platform was named an American Association of State Highway and Transportation Officials (AASHTO) Innovation Initiative. Deployed across the state, the system allows UDOT to monitor and manage signal operations for all signals maintained by the agency while aiding in more efficient travel flows along corridors.
From 2006 to 2013, the Indiana Department of Transportation (INDOT), with Purdue University, established a testbed of signal performance measures. INDOT developed a common platform for collecting real-time signal data, which became the foundation for AASHTO’s Innovation Initiative on Signal Performance Measures. This performance system has now been deployed at more than 3,000 intersections across the country.
Researchers at The College of New Jersey have established a signal performance measurements testbed using Burlington County’s centralized traffic signal management system. Traffic signal data collected along County Route 541 has been used to generate real-time performance measures and identify infrastructure improvements that could advance NJDOT’s ability to use real-time SPMs. An example of the existing real-time performance monitoring for Irwick Road and CR541 in Westhampton, NJ in Burlington County is shown in Figure 1.
Many state or local agencies including Pennsylvania DOT, Michigan DOT, New Jersey DOT, Lake County (Illinois), and Maricopa County (Arizona), etc., are actively incorporating ATSPMs into their traffic management and operation strategies. Lessons learned from implementation of ATSPMs from different agencies revealed that ATSPMs are critical to ATCS.

The research team organized and facilitated targeted stakeholder meetings. These meetings confirmed that stakeholders were not currently able to perform efficient real-time post-processing of the existing available data. Through the meetings, the research team was able to scope more deeply into the type of performance measurements that were feasible and what could be done with the collected information. Stakeholders also conveyed that the total number of operating adaptive signal intersections would more than double in the near-term future, making the need to efficiently process and leverage data from adaptive systems a more pressing concern. The discussions further confirmed that the big question for study was how to best leverage these adaptive systems to evaluate and manage future corridors.

Figure 2. Corridors where NJDOT has deployed ASCT systems; red denotes full operation, yellow denotes under construction, and blue denotes concept development

The research team sought to better understand the inventory of NJDOT’s existing and planned ASCT systems. In 2019, New Jersey had over 2,500 NJDOT-maintained signals, but only 76 signals were on Adaptive Traffic Signal Systems. In addition to the existing five corridors and the district in which ASCT systems had been deployed, 3 corridors were under construction and/or in final design and another 11 corridors were in the concept development phase for future ASCT installation at the time of the study (see Figure 2).

The research team visited the state’s Arterial Management Center (AMC) and investigated several signal performance systems – specifically, the Sydney Coordinated Adaptive Traffic System (SCATS), Rhythm Engineering’s InSync, and the Transportation Operations Coordinating Committee’s (TRANSCOM) real-time data feed – to better understand their interfaces, different types of detectors and their availability.

Figure 3. System Operation Data Flow Diagram

The research team designed an automated traffic signal performance measurement system (ATSPM) based on existing ATSPM open-source software to develop an economically justifiable ATSPM for arterial traffic management in New Jersey. The entire system operates as shown in Figure 3. The high-resolution controller belonging to existing infrastructure is connected to an AMC at each signalized intersection. The controller event log file contains signal state data that is sent to an AMC database. The research team’s program automatically retrieves these data logs and translates the unprocessed data into a standard event code. The converted event file is inserted into an ATSPM database and the ATSPM software can generate signal performance metrics and produce visualizations to support performance-based maintenance and operations by traffic engineers.

Key Research and Implementation Activities

The research team successfully created a bench test of the ATSPM system based on data collected from high-resolution data from adaptive signal control systems including 13 SCATS locations on NJ Route 18 and 2 InSync locations on US Route 1. As a result of the testing, the research team successfully assembled a prototype for automated traffic signal performance measures in New Jersey.

Key research activities from the project are as follows:

Create Inventory of Existing NJDOT Arterial Management System: The team investigated several signal performance systems including InSync, SCATS, and TRANSCOM fusion application interfaces and different types of detectors and their availability. The team also conducted intensive review of state-of-the-art-and-practice of ATSPM system and identified ways of migrating the system to NJ.
Identify Performance Metrics and Measurement Methods for NJDOT ATSPM System: The team conducted a comprehensive review of SPMs built into an ATSPM system. The team investigated and customized SPMs that can be generated by NJDOT detector and travel time data.
Develop System Architecture and Concept of Operations for NJDOT ATSPM System and Established a Bench Test of ATSPM Located on TCNJ’s Campus: To leverage the existing ATCS system, the team developed a signal event conversion program to translate existing SCATS and InSync history log file to an event code that can be recognized by ATSPM. The detailed metrics are summarized in the figures to the right.
Prepare Real-Time Traffic Signal Data Management Guidelines: The research team created data management guidelines and a manual for data processing. The team validated the outputs through a comprehensive process. The team also completed a test to automatically connect to an ATSPM database using a VPN and MSSQL database management system.
Develop Deployment Strategies Considering Existing, Planned, and Future Systems/ Conduct Case Studies of System Deployment: The team initiated the pulling of one-month of data into their platform for the ATSPM. Large scale deployment of this system was expected to be conducted as part of Phase II research.

The research team observed that ATSPMs have distinct advantages over traditional traffic signal monitoring and the accompanying management process. The systems help shorten feedback loops with easier data collection and signal performance comparisons to enable before and after timing adjustments.

Future Work

In the first phase of the research project, the research team developed a software toolbox, NJDOT ATSPM 1.0. The toolbox can convert the event output data from SCATS and InSync ATSC Systems into event data that can be processed by the ATSPM platform. The primary accomplishment was to integrate ATSPMs with existing ATCS from the centralized management console, instead of configuring at each controlled intersection on field. The proposed system bridges the gap between increasingly deployed ATSC and emerging ATSPMs without investment on new controllers. The effect of this research was validated on two selected corridors. NJDOT arterial management operators are able to use the ATSPM platform to generate key performance metrics and conduct system analysis for NJDOT’s ATSC corridors.

While the initial deployment and analysis was successful, it was limited in its scope. Phase II of the research involves the development and deployment of a significantly-enhanced version of the original toolbox, NJDOT ATSPM 2.0, along with a pilot study on the integration of ATSC controllers with Connected Autonomous Vehicle (CAV) technologies.

The research team will work with NJDOT to identify and add new performance metrics to generate additional Signal Performance Measures. The team can incorporate proprietary data from traveler information providers (e.g. INRIX and HERE) to generate other performance metrics such as queue/wait time, degree of saturation, predicted volumes, etc., and incorporate them into the NJDOT ATSPM platform. The team will also conduct pilot testing on the integration of Connected and Automated Vehicle (CAV), Roadside Units (RSU), On Board Unit (OBU) with the existing and planned NJDOT ATSC systems.

This developed ATSPM system from Phase II will bridge the gap between collected traffic data (e.g., signal controller data, detector data, and historical data) and needed performance information for decision-making. Phase II research is underway with an expected completion by November 2021.

Relationship to Strategic Goals

The development of RT-SPMs and the adapting and deployment of ATSPM with existing NJ ATSC systems is aligned with the FHWA EDC (Every Day Counts) Initiative to promote the rapid deployment of proven innovations. NJDOT ATSPM 2.0 will help meet the strategic EDC goal to accelerate the deployment of ATSPMs on existing and planned arterial corridors to reduce crashes, injuries, and fatalities, optimize mobility and enhance the quality of life.

The Phase II research supports the state initiative on advancing policy and testing of CAV technologies in New Jersey. The outcome of the project will be reported to NJDOT which is part of the New Jersey Advanced Autonomous Vehicle Task Force to make recommendations on laws, regulations and guidance to safely integrate advanced autonomous vehicle testing on the State’s highways, streets, and roads.

Resources

McVeigh, Kelly. (2019). Automated Traffic Signal Performance Measures. Presentation at NJ STIC May 7^th, 2019 Meeting.

Jin, P. J., Zhang, T., Brennan Jr, T. M., & Jalayer, M. (2019). Real-Time Signal Performance Measurement (RT-SPM) (No. FHWA NJ-2019-002). Retrieved at: https://www.njdottechtransfer.net/wp-content/uploads/2020/01/FHWA-NJ-2019-002.pdf

Jin, P. J., Zhang, T., Brennan Jr, T. M., & Jalayer, M. (2019). Real-Time Signal Performance Measurement (RT-SPM) – Technical Brief Retrieved at: https://www.njdottechtransfer.net/wp-content/uploads/2020/01/FHWA-NJ-2019-002-TBrev.pdf

Zhang T., Jin P., Brennan, T., McVeigh, K. and Jalayer, M, Automating the Traffic Signal Performance Measures for Adaptive Traffic Signal Control System. ITS World Congress. 2020.

Lunchtime Tech Talk! WEBINAR: Evaluation of Precast Concrete Pavement Systems and State Specifications

Posted on June 11, 2020July 1, 2021

On June 10, 2020, the NJDOT Bureau of Research hosted a Lunchtime Tech Talk! Webinar on "Evaluation of Precast Concrete Pavement Systems and State Specifications.” Dr. Yusuf Mehta, Director of Rowan University’s Center for Research and Education in Advanced Transportation Engineering Systems (CREATEs), introduced the presentation and acknowledged the contributions of individuals and other state DOTs to the research effort. Dr. Daniel Offenbacker began the presentation with a description of the research study performed for NJDOT to identify, evaluate, and compare precast pavement systems, specifications, and practices currently in use for Precast Concrete Pavement (PCP). The study included an extensive literature review and surveys with Subject Matter Experts from various state DOTs that have experience with precast concrete pavement rehabilitations.

Dr. Offenbacker discussed the benefits and drawbacks of Precast Concrete Pavements.

Rigid pavements play an important role in highway infrastructure, primarily in regions with high traffic density such as New Jersey. NJDOT is continuously exploring innovative pavement rehabilitation strategies, such as Precast Concrete Pavement (PCP), that allow for faster and more durable rehabilitation of rigid pavements. Precast concrete is cast off-site to specifications and installed to match a particular location. Dr Offenbacker noted the benefits of precast concrete systems including quick installation that limits the duration of road closure and requires minimal interaction with drivers. The material is durable and long-lasting. Drawbacks include the high cost, challenges to installation requiring tight specifications, and limited capability among contractors and systems.

The researchers surveyed 17 states and followed up with 8 states that are using PCP systems. Other states shared experiences with systems in use, standards for manufacture and installation, permitting of new systems, and experiences with installation and performance. Eight different state specifications were identified that addressed panel fabrication, bedding and grout stabilization, installation tolerances, and encasement grout.

The research led to the conclusion that installation is critical to PCP performance. Failure is generally due to misalignment or poor leveling. Dr. Offenbacker described a proposed five-step system approval process to be used in New Jersey for acceptance of newly-developed precast pavements. The approval system included materials and slab approval, demonstration of system installation, and proof of performance. Recommendations included use of documented experiences from other states in establishing specifications and exploring development of a generic PCP system for New Jersey.

The research resulted in recommendations for a Precast Concrete Pavement approval process for use in New Jersey

Dr. Offenbacker noted the need for future work to investigate the long-term performance of PCP systems, to prepare a life cycle cost analysis to quantify the economic benefits, to assess the usefulness of intermittent precast systems in light of surrounding pavement deterioration, and to develop a training platform for contractors to insure proper installation.

Following the presentation, participants posed questions via the chat feature. Responding to a question about the use of planar vs. non-planar slabs, Dr. Offenbacker noted that the existing conditions of the roadway would determine which slab would be used to match the existing structure.

A participant asked if there was any criteria for choosing between rapid-set concrete and PCP. Dr. Offenbacker responded that there was no criteria yet for when one would choose one over the other.

A participant asked what Dr. Offenbacker considered the key takeaway from the surveys. He responded that installation was the key consideration. He emphasized the need to understand the economic benefits of PCP, which are starting to outweigh the benefits of other rehab techniques such as rapid-set.

In response to a question about training needed, Dr. Offenbacker noted that training is needed in the specific systems. California requires each contractor to go through a certification process if they want to use precast pavement systems on a regular basis.

A participant asked if deterioration of slabs adjacent to a replacement slab was due to the replacement slab. Dr. Offenbacker replied that the replacement slab would not cause deterioration if installed properly. The roadway may be deteriorating incrementally.

A participant asked if the Federal Highway Administration (FHWA) provided input on QA/QC for underslab grouting and grouting dowel bar slots. Dr. Offenbacker responded that there are thorough specifications for these elements and they are available in the final report.

In response to a question about whether there is a maximum and minimum size for PCPs and how that correlates to performance, Dr. Offenbacker noted that this has not been explored well yet. The typical length is 15 feet.

The presentation given by Dr. Mehta and Dr. Offenbacker can be downloaded here.

For more information about the research study, please access the final report and technical brief here.

For more information about research at Rowan University's CREATES, click here.

A recording of the presentation is also available here (or see right).

NJ STIC 2020 Spring Meeting

Posted on May 11, 2020August 18, 2021

NJ STIC’s first virtual meeting on May 6, 2020

The NJ State Transportation Innovation Council (NJ STIC) Spring 2020 Meeting focused on the EDC-5 Innovative Initiative Virtual Public Involvement. The topic was appropriate to the times as STIC members gathered for the group’s first virtual meeting in response to NJ Executive Order 107 in force during the COVID-19 pandemic. The STIC Meeting Agenda had been distributed to the invitees prior to the May 6, 2020 meeting. Participants could use the chat feature to offer comments or ask questions of the speakers during the meeting.

After his Welcome and Opening Remarks, Asst. Commissioner Michael Russo introduced NJDOT Commissioner Diane Gutierrez-Scaccetti who emphasized the distinction between virtual meetings, public meetings, and public hearings. She noted that NJDOT’s work continues during the lockdown and the agency will be instrumental in helping the state get back on its feet once re-opening begins. Division Administrator for the FHWA NJ Office, Robert Clark, and Amanda Gendek, Manager of the NJDOT Bureau of Research, rounded out the Welcome and Opening Remarks setting the stage for primary focus of the Spring Quarterly STIC meeting on the implementation of Virtual Public Involvement (VPI) in everyday activities of transportation agencies.

Jill Stark from FHWA reviewed online tools to increase public involvement (click for presentation)

The meeting continued with presentations from representatives of FHWA, New Jersey’s three Metropolitan Planning Organizations, Monmouth County, Princeton and industry discussing how they have adapted to the need for virtual public meetings and the benefits and challenges associated with the transition to the online formats.

VPI Tools and Techniques - Jill Stark and Lana Lau from FHWA presented several resources, such as mobile apps, crowdsourcing tools, project visualizations, and online mapping, to enhance public involvement and offered several examples of their use in other state transportation agencies. Ms. Stark noted that virtual public involvement will not replace in-person meetings but can supplement traditional engagement activities.

DVRPC used the chat feature during the board meeting to take public comment (click for presentation)

During their talk, the FHWA identified several resources, including webinars and fact sheets, available on Virtual Public Involvement. The agency is also creating videos that highlight innovative and virtual public engagement strategies in use in state and local transportation agencies. An article on the videos, including the fact that NJDOT and NJTPA activities were featured examples, was the subject of a recent post on the NJDOT Technology Transfer website.

MPO representatives reported on the need for quick technological transitions to remote work, experiences with online platforms, and related lessons learned.

NJTPA’s online survey was available in translation and participants could leave comments (click for presentation)

DVRPC: Virtual Meeting Best Practices - Barry Seymour and Alison Hastings from DVRPC discussed increased public participation at their recent board meeting and the request for remote access to meetings going forward. Noting that reaching underserved communities just got harder, they emphasized features of their chosen meeting platform that increase accessibility, such as phone and computer audio, an app for cell phones, and closed captioning and audio channels for live translation.

Virtual Public Involvement - Mary Ameen and Melissa Hayes from NJTPA offered tips for online discussions, advocating for gearing the message to the audience, keeping meetings brief, providing multiple feedback options, and making the meeting mobile-friendly. Their Virtual Public Engagement Best Practices guidance is available online. They also offered examples from municipalities using online tools to reach their communities.

SJTPO is looking for alternatives methods of reaching populations lacking internet access (click for presentation)

Virtual Outreach During COVID-19 in the SJTPO Region - Jennifer Marandino and Alan Huff from SJTPO spoke about the agency’s dive into the issue of limited access to online public involvement opportunities in low-income and minority communities. They have discovered areas in their region that require focused in-person public involvement. The agency is delaying public involvement on major issues and exploring alternative means for reaching the region’s population.

Monmouth County used a project website to inform the public and gather feedback (click for presentation)

Monmouth County Bridge Replacement Projects: Virtual Public Meetings – County Engineer Joseph Ettore and Consultant Martine Culbertson spoke about the limitations of virtual meetings and the impact on project development on two Bridge Replacement Projects in Monmouth County. The speakers discussed design of a project website, the challenges of virtual public meetings, how to proceed when a project faces some local opposition, and the need to keep projects on track to retain funding.

Princeton used various methods to track and display feedback from public involvement activities (click for presentation)

Virtual Public Involvement: A Municipal Perspective - Deanna Stockton, Engineer for Princeton, discussed the challenges related to bid openings, and holding council, zoning board and planning board meetings, and shared some useful resources. She noted the need to meet MLUL requirements and deadlines associated with zoning and planning board project reviews and discussed the creation of permanent digital files.

Industry Presentation: Virtual Consultation Platform - The final presentation, from Orla Pease and Andy Thomas of AECOM, offered a STIC industry partner perspective, and highlighted a new online virtual meeting platform. The meeting closed with a brief question and answer session.

The Spring Quarterly STIC meeting offered an abundance of useful information, tips, and lessons learned related to virtual public involvement tools and strategies.

A recording of the NJ STIC Spring 2020 Meeting can be found here and to the right. There was insufficient time to answer all questions posed during the session. Answers to these questions can be found here.

The NJ STIC Spring Virtual Meeting Presentation can be found in its entirety and in sections below.

Click for entire presentation (10MB).

Virtual Meeting Best Practices by DVRPC

Monmouth County Bridge Replacement Project Virtual Public Meeting

Q&A and Thank You

Welcome and Opening Remarks

Virtual Public Engagement by NJTPA

Virtual Public Involvement: A Municipal Perspective

Presentation by FHWA

Virtual Outreach During COVID-19 in the SJTPO Region

Industry Presentation, Virtual Consultation Platform

Reducing Rural Road Departures: Upcoming FHWA Webinar and Other Resources Advance EDC-5 Initiative

Posted on April 24, 2020April 24, 2020

FHWA Storyboard

On May 12, 2020, the Federal Highway Administration will host FoRRRwD on All Public Roads: Innovative Mechanisms to Deliver Safety Projects, the second of its monthly webinars designed to help reduce rural roadway departures and save lives. Reducing rural roadway departures is one of the ten initiatives addressed by the 5th round of its Every Day Counts program (EDC-5). The EDC program identifies and deploys proven innovations to save state departments of transportation time, money, and resources. This webinar is the latest FHWA offering of technical materials aimed at reducing roadway departures (see below). Other recent materials include:

A storyboard on horizontal curve warning signs. The storyboard demonstrates the effectiveness of low-cost solutions such as advance warning signs and curve chevrons to reduce crashes on curves, especially at night.
An informational video. Released in late March 2020, this video showcases the benefits of rumble strips in reducing road departures. The video notes that rumbles strips can reduce departure crashes by up to 50 percent. (Embed the video here)
An innovation spotlight video. This 2019 video highlights key countermeasures to prevent or reduce severity of crashes, and systemic analysis tools agencies can use to prioritize locations on a network with high risk for future crashes.

New Jersey has also been working to address this issue, using some of the methods listed above on rural roads across the state. This recent NJDOT Tech Transfer article highlights how Cumberland and Somerset Counties are reducing rural road departures along high risk portions of their networks.

FoRRRwD on All Public Roads: Innovative Mechanisms to Deliver Safety Projects

May 12, 2020
1-3 pm

Rural roadway departures make up a third of U.S. traffic fatalities—about 30 people a day. The Every Day Counts round five (EDC-5) initiative, Focus on Reducing Rural Roadway Departures (FoRRRwD), features four pillars: 1. Addressing All Public Roads, 2. Systemic Approach, 3. Safety Action Plans, and 4. Proven Countermeasures.

This webinar focuses on the first pillar. State, local, and tribal agencies come learn unique approaches and methods that you can use to efficiently deliver safety countermeasures and projects to reduce rural roadway departure crashes. Speakers and Topics to be covered include:

Steve Landry, Maine DOT, will discuss Maine DOT’s use of safety supply (Curve Warning Signs, RRFBs, Speed Feedback Signs) procurement projects where state procurement procedures are used, and local public agencies or State forces perform installation at their cost.
Mark Thomas, Mississippi DOT (MDOT), will discuss how agencies in Mississippi have used agency force account to deliver roadway departure countermeasures, and a program where MDOT provides warning and advisory signage to local governments to install.
Patricia Burke, Montana DOT (MDT), will discuss MDT’s use of Job Order Contracting to streamline the delivery of safety projects.

This webinar is free and open to anyone who is interested. Registration is limited to 500 seats.

Registration: Participants must register in advance at https://collaboration.fhwa.dot.gov/dot/fhwa/WC/Lists/Seminars/DispForm.aspx?ID=2260

Please Note: Non-USDOT employees who have never participated in an FHWA webinar must create an account at https://collaboration.fhwa.dot.gov/FBA/MembershipRequest.aspx in order to register for this webinar.

FHWA recommends using Microsoft Edge or Internet Explorer for optimal registration experience.

FHWA’s Ray Murphy Presents EDC-5 Weather-Responsive Management Strategies

Posted on April 15, 2020July 1, 2021

On April 14, 2020, the NJDOT Bureau of Research hosted a Lunchtime Tech Talk! webinar on "EDC-5 Weather-Responsive Management Strategies." This event featured a presentation by Ray Murphy, ITS Specialist with the FHWA's Resource Center. Under Round 5 of the Every Day Counts (EDC) program, FHWA promotes Weather-Responsive Management Strategies (WRMS) to manage traffic and road maintenance during inclement weather to improve safety and reliability, and minimize environmental impacts associated with weather events. Weather affects: traffic safety, with 21 percent of the nearly 6 million roadway crashes in the past decade related to weather; mobility, resulting in reduced efficiency and productivity; and environmental impacts on watersheds, air quality, and infrastructure.

Mr. Murphy provided examples of weather responsive practices being tried by state DOTs, including an advanced traveler information notification deployed by Iowa DOT.

Mr. Murphy described the prior-round, EDC-4 innovation, Road Weather Management – Weather-Savvy Roads, that formed the basis for this EDC-5 initiative. The innovation promoted data collection including Pathfinder, a collaboration between the National Weather Service, state DOTs, and state support contractors to provide weather information and forecasts, and Integrating Mobile Observations (IMO) that collects weather and road condition data from instruments on agency fleet trucks.

Through WRMS, FHWA promotes the use of mobile data to support decision making. Benefits to agencies include improved safety, system performance and operations, and reduced costs and environmental impacts. Agencies can use Weather Responsive Management Systems to address diverse internal needs such as staffing, material use, and route optimization, and condition and performance reporting. Data sources include transportation agency fleets, private vehicles, third party entities, agency operators, road users and infrastructure. Some data is collected by in-vehicle sensors, video and camera images, and automatic vehicle location. Other data sources include fixed Roadway Information System (RWIS), National Weather Service, reports from road users and operators, mobile observations and connected vehicle data, among others.

The traveling public benefits through safer pre-trip and real-time route decision making based on enhanced traveler information, roadside messaging, variable speed limits, and road lane closures or restrictions. Unified, localized, and more accurate messaging gives the public increased confidence in the messaging and the agency.

Mr. Murphy addressed some common challenges that agencies face in adopting this innovation, such as a lack of connectivity in remote areas, the need for buy-in from agency leadership and from road crews, hesitance to adopt the innovation, and funding.

Mr. Murphy cited some of work that NJ DOT has accomplished in the field of Weather Responsive Management Strategies.

Mr. Murphy highlighted recent initiatives undertaken by NJDOT related to Weather Responsive Management Strategies that have been funded in part through FHWA innovation grants.

He noted that the State Transportation Innovation Council (STIC) Incentive Program and STIC Accelerated Innovation Deployment (AID) grants can help fund implementation of these technologies. NJDOT received a STIC incentive funding grant to support pilot testing of technology used by the Safety Service Patrols. NJDOT was also awarded an AID Grant from FHWA to support a weather savvy roads pilot program, installing video camera dashboards and sensors onto NJDOT maintenance trucks and safety service patrol vehicles to collect streaming video and weather / pavement information to support road weather management throughout the state.

Webinar participants had an opportunity to pose questions of Mr. Murphy. One participant asked about possible resistance to installation of automatic vehicle locators due to privacy concerns. Mr. Murphy noted that agencies must operate openly and inclusively when implementing this technology. Training and education can help users become more accepting of the technology.

A participant asked about the use of IMO data versus information gathered from a public entity such as WAZE. Mr. Murphy responded that the agency receives the IMO data directly and can oversee the accuracy of the data, but that information should come from multiple sources to create a robust dataset.

When asked what agencies consider the biggest challenges, and what arguments can be used to support this innovation, Mr. Murphy responded that funding is always a concern but that buy-in is often the larger issue. He emphasized the need for a champion who can demonstrate the benefits of the strategies through performance measures.

When asked if specific applications of WRMS were being considered for EDC-6, Mr. Murphy responded that various innovative practices were being considered and no decisions had been made yet.

A participant asked if these systems can be adapted to rockfall data. Mr. Murphy noted that visibility apps used with dust storms or fire events could be adapted for other weather events.

Mr. Murphy’s presentation offered several examples of DOTs nationwide employing these strategies. A participant asked if any states are quantifying the benefits of WRMS implementation. Mr. Murphy offered that Caltrans is one agency.

The presentation given by Mr. Murphy can be downloaded here.

More information on this innovation is available on the FHWA Weather Responsive Management Systems resources page.

A recording of the webinar is available here, (also to the right).

Federal Highway Administration Releases Second EDC-5 Progress Report

Posted on April 8, 2020April 17, 2020

The second EDC-5 Progress Report summarizes the deployment progress of the 10 innovations in the fifth round of the the Federal Highway Administration’s Every Day Counts program for July through December, 2019. The EDC program coordinates the deployment of new strategies and technologies within State Departments of Transportation. These strategies help transportation stakeholders to shorten the project delivery process, enhance roadway safety, reduce traffic congestion, and integrate automation to better serve the nation.

The national report analyzes each state’s implementation stages for the 10 innovations using charts and maps. The report also presents the number of states that have demonstrated, assessed, or institutionalized innovations, and presents goals for how many states should reach these stages by December 2020. New Jersey Department of Transportation has fully institutionalized Crowdsourcing for Operations, Project Bundling, and Unmanned Aerial Systems. The agency has reached the assessment stage for Safe Transportation for Every Pedestrian, and the demonstration (testing and piloting) stage for Advanced Geotechnical Exploration Methods and Collaborative Hydraulics. Two other innovations are in the development phase.

FHWA compiles a progress report every six months regarding the state of practice for the current round of EDC initiatives. An online version of the EDC-5 Progress Report can be found here.

NJ Transportation Agencies Featured for Their Innovative and Virtual Public Involvement Approaches

Posted on April 8, 2020November 30, 2022

FHWA promotes virtual public involvement and other innovative public involvement tools through its Every Day Counts-5 innovations. FHWA notes several benefits of a robust public involvement process that employs technology to bring public involvement opportunities to people. These techniques tend to be more efficient and cost-effective, help to accelerate the project delivery process by identifying issues early in the process, ensure that the needs and desires of community members are heard in a collaborative process, and improve project quality by reaching individuals who might otherwise not be engaged.

FHWA is developing a series of short videos highlighting virtual public involvement tools, as well as other innovative strategies, in use at state and local transportation agencies. Approaches in use by New Jersey Department of Transportation (NJDOT) and North Jersey Transportation Planning Authority (NJTPA) feature in several of these videos.

NJTPA used Set the Table, a meeting-in-a-box, to gather input from millennials for the agency’s long-range regional plan (Plan 2045). Individuals hosted small dinner parties for their peers (aged 18-30). Boxes, similar to pizza boxes, held snacks, and conversation cards on seven focus areas related to transportation. Twenty events were held, reaching over 200 individuals. Participants voiced an interest in staying involved in the planning process.

To supplement print and other media advertisement to gather public input for Plan 2045, NJTPA used online ads geo-targeted to the region. These ads invited people to participate in an online survey covering the Plan’s seven focus areas. The campaign reached 1.6 million people over six weeks and received a robust response. The agency found that this virtual engagement strategy not only reached people where they were, but helped to inform a large number of people about the transportation planning process and the agency.

In-person public engagement events continue to have real value. To encourage public involvement on the Pulaski Skyway rehabilitation project, NJDOT used pop-up outreach at the Liberty Science Center in Jersey City. During construction, lane closures on the highway would affect 35,000 regional commuters and local residents on a daily basis. Wishing to reach a local population, many of whom were unlikely to attend a community public involvement meeting, NJDOT brought the meeting to them. A booth presented information and displayed a piece of the deteriorating bridge to explain to children and adults the importance of the highway project.

In delivering these examples, FHWA emphasizes the need for transportation agencies to expand their outreach efforts to engage people in their everyday lives.

STEP-Aligned HAWK Signal Installed in Bergen County

Posted on March 20, 2020March 20, 2020

Every Day Counts (EDC) is an initiative developed by the Federal Highway Administration’s (FHWA) Center for Accelerating Innovation to improve safety along our roadways. Every two years, EDC identifies a number of highway safety innovations that are then supported for rapid deployment. A set of innovations targeted at pedestrian safety was identified within the 2019–2020 EDC cycle. Safe Transportation for Every Pedestrian (STEP) provides a set of pedestrian improvements ranging from small scale signage installation to fully revamped roadway layout through road diets. STEP-aligned projects have been successfully deployed in locations across New Jersey, including a recent pedestrian improvement project along Washington Avenue in the Borough of Carlstadt in Bergen County, New Jersey.

Washington Avenue is a four-lane, bidirectional road with a speed limit of 40 miles per hour. The corridor hosts a number of industrial businesses and therefore witnesses a great deal of truck traffic. Many employees working at these sites arrive by bus and dash across the four lane roadway to avoid walking 700 feet to the nearest lighted intersection at Veterans Boulevard.

In early 2013, a pedestrian fatality occurred along the corridor. According to Christine Mittman, North Jersey Transportation Planning Authority, concerned county officials submitted an application to the North Jersey Transportation Planning Authority (NJTPA) through the Local Safety Program which utilizes Highway Safety Improvement Program funds. In order to develop comprehensive and effective solutions for the corridor, the New Jersey Department of Transportation and NJTPA recommended a road safety audit for a 1.6-mile section of Washington Avenue from Moonachie Avenue to Road A, just north of the Paterson Plank Road.

Figure 1. At this location along Washington Avenue, pedestrians were forced to walk in the travel lane (photo credit: Christine Mittman, NJTPA).

A road safety audit is a tool promoted by FHWA to identify safety issues for all users along a designated area of roadway. An independent multidisciplinary team walks the corridor observing and taking notes related to safety concerns, user conflicts, and roadway performance issues. Often the auditors use a standardized form to take notes about each section of the corridor being studied. Some issues that may arise include missing street lights, uneven sidewalks, areas where turning conflicts are common, and high volumes of pedestrians crossing the roadway outside of crosswalks. Additional guidance from FHWA can be found here.

During the Washington Avenue road safety audit, it became obvious that the pedestrian infrastructure along the corridor was insufficient. Paths were worn into the grass along either side of the roadway where sidewalks were missing. Workers crossed the road all along the corridor as trucks flew by. In some areas of the corridor, pedestrians were forced to walk within the vehicular travel lane as the pedestrian right of way was blocked and there was no shoulder along Washington Avenue (see Figure 1). The situation was clearly dangerous.

Once the recommendations were made through the road audit report, the project was advanced through the Local Safety program which included funding for both design and construction. A number of recommendations from the report made it into the final designs, including several pedestrian safety improvements at Barrell Avenue. These recommendations included completing the sidewalk network, relocating the bus stops for safer pedestrian crossings, and extending the Jersey barrier median with fencing along the top. The most innovative part of the design was the installation of a high-intensity activated crosswalk beacon (HAWK) signal, the first of its kind in Bergen County.

A HAWK signal, or Pedestrian Hybrid Beacon, is a traffic control signal that assists pedestrians in locations where a traffic intersection is not signalized. When pedestrians are not present, the HAWK signal is unlit. But, as its name implies, when the HAWK is activated by the push of a button it proceeds through a light sequence that stops traffic while the pedestrian safely crosses the roadway with a countdown. A video of the HAWK signal control process can be found here.

A HAWK signal was installed just north of the intersection of Barrell Avenue and Washington Avenue for a number of reasons (see Figure 2). The first consideration was the high volume of pedestrian traffic coupled with a lack of traffic control at the T-intersection. Secondly, the area is situated about midway between the two nearest signal controlled intersections with pedestrian crosswalks. Additionally, the overhead nature of the HAWK plays a much stronger role in capturing drivers’ attention as compared to placing rectangular rapid flashing beacons on either side of the roadway. Bus stops were relocated on either side of Washington Avenue near the HAWK signal to ensure the stops are safely accessible to patrons from both sides of the roadway.

Figure 2. HAWK signal located north of the intersection of Barrell Avenue and Washington Avenue.

According to Nancy Dargis from the Bergen County Division of Planning and Engineering, local officials were concerned that drivers would not understand how to respond to the new signal. However, since the project’s completion in late 2018, driver compliance rates have been high according to the Carlstadt Police Department. A post-implementation crash data analysis will be performed once three years of data is available, at which time more details will be available regarding the HAWK signal’s effectiveness on Washington Avenue.

Additional research related to the general effectiveness of HAWK signals is currently being undertaken by an NJDOT-funded study out of Rutgers University’s Alan M. Voorhees Transportation Center and Rowan University. The study seeks to measure both the public’s understanding of the HAWK signal and its effectiveness in increasing driver yielding at pedestrian crossings. The study will be completed this year.

The Washington Avenue HAWK signal was part of a $4.2 million project improving the safety of a 1.6-mile corridor of Washington Avenue. The project costs included sidewalk installations, drainage, new and upgraded signals, ADA compliance improvements throughout the corridor, guardrail upgrades, and an extended Jersey barrier median with six feet of fencing along the top.

Officials learned during implementation that the fencing along the median barrier would create sight line issues for drivers approaching the crosswalk when pedestrians were in the crosswalk on the opposite side of the road. After some research, they determined the safest course of action would be to take down the fencing for the 100 feet approaching the crosswalk in both directions. Additionally, officials pointed out the importance of installing the HAWK signal at an appropriate location. Specifically, the HAWK signal should not be placed at an intersection in place of a full traffic signal. The Washington Avenue HAWK signal is installed near, but not at, the Barrell Avenue intersection which is a T-intersection with a minimally trafficked side street.

The Washington Avenue HAWK signal was the first HAWK signal installed in Bergen County, and so far it has been a success. The signal has been seamlessly incorporated into the traffic movements in the area and local officials are happy with the results. Several more HAWK signals are in the works in locations throughout the NJTPA region as officials work to implement safety improvements aligned with the EDC STEP initiatives.

RESOURCES

Every Day Counts Initiative: https://www.fhwa.dot.gov/innovation/everydaycounts/about-edc.cfm

Safe Transportation for Every Pedestrian (STEP): https://www.fhwa.dot.gov/innovation/everydaycounts/edc_5/step2.cfm

FHWA Road Safety Audit information and resources: https://safety.fhwa.dot.gov/rsa/

NJDOT videos describing FHWA’s Pedestrian Safety Countermeasures: https://www.njdottechtransfer.net/2019/09/27/njdot-safety-countermeasures-videos/

FHWA HAWK information and statistics: https://safety.fhwa.dot.gov/provencountermeasures/ped_hybrid_beacon/

This article is cross-posted on the NJ Bike & Pedestrian Resource Center blog.
